Features
1. Uses ZN385Q/ZN390Q engine manufactured by Changchai Co., Ltd. to deliver smooth start-up performance.
2. The rear-drum drive available gearbox for motion transmission. Front drum roller delivers extra compaction from vibration.
3. Hinged bodywork, power steering, fork-shaped axle holder with more than 600mm curb and side clearance
4. Gearbox has Japanese technology built in it for easy gear shift.
5. Offers 3 gears to achieve excellent compaction result and make it easier to transfer between compaction sites.
6. Platform trailer is optional.
7. Built with 2 patented technologies.
| Operating mass | 3000kg |
| Centrifugal force | 32kN |
| Vibration frequency | 50Hz |
| Vibration amplitude | 0.5mm |
| Traveling speed | 2.5km/h 5.2km/h 8km/h |
| Grade ability | 20% |
| Dimension | 2850×1275×2600mm |
| Engine model | ZN385Q |
| Engine power | 21kW |
| Turning radius | 4500mm |
| Drum width | 1100mm |
| Wheel base | 2050mm |
| Water tank capacity | 100L |
